Understanding Kubernetes and Its Core Components – A Technical Deep Dive

vivek

If you've spent any time in the world of DevOps, SRE, or modern software delivery, you've heard the word Kubernetes (or just K8s). But beyond the buzzword status, Kubernetes is a powerhouse system for managing containerized workloads at scale with flexibility, resiliency, and automation baked in.

In this blog, we'll break down the core components of Kubernetes, explain how they work together under the hood, and help you understand what actually runs inside a Kubernetes cluster.

What Is Kubernetes?#

What is Kubernetes - Developer understanding Kubernetes architecture and container orchestration

Kubernetes is an open-source container orchestration system originally developed by Google and now maintained by the Cloud Native Computing Foundation (CNCF). Its primary job is to automate deployment, scaling, and management of containerized applications.

Think of Kubernetes as the operating system for your cloud-native applications — providing the abstraction and control layer for apps running in containers (like those built with Docker, Podman, etc.).

Learn more about : Kubernetes official documentation

High-Level Architecture: Control Plane vs. Node Components#

A Kubernetes cluster is split into two main categories of components:

  • Control Plane – the brain of the cluster
  • Node Components – the workers that run containers

Let's break them down.

Control Plane Components#

The Control Plane manages the overall state of the cluster. It makes decisions (e.g., scheduling, reacting to failures) and exposes APIs for cluster interaction.

1. kube-apiserver#

  • The front door of the cluster. Every request — from kubectl, Helm, CI/CD pipelines — hits the kube-apiserver.
  • Stateless and can be scaled horizontally.
  • Validates and processes REST requests, then updates the desired state in etcd.

For more details about API Server deep dive

2. etcd#

  • A highly available key-value store used as Kubernetes' single source of truth.
  • Stores all cluster data: nodes, pods, secrets, configs, etc.
  • Built for distributed systems with strong consistency guarantees.

🔗 What is etcd?

3. kube-scheduler#

  • Watches for unscheduled pods and assigns them to appropriate nodes based on:
    • Resource availability
    • Affinity/anti-affinity rules
    • Node taints/tolerations
    • Custom scheduling rules

Know more about Scheduling concepts

4. kube-controller-manager#

  • Runs all the built-in controllers as separate loops: replication controller, job controller, service account controller, etc.
  • Each controller compares the desired state (from etcd) vs. the current state and makes adjustments.

🔗 Controller Manager

5. cloud-controller-manager#

  • In cloud environments (AWS, GCP, Azure), this separates cloud-specific logic — like attaching volumes or provisioning load balancers — from the core controllers.

Node Components#

Kubernetes Node Components - kubelet, kube-proxy, and container runtime architecture

These components run on every worker node in the cluster and are responsible for running and managing containers.

1. kubelet#

The primary node agent. It:

  • Talks to the kube-apiserver
  • Ensures the containers are running as specified in PodSpecs
  • Collects pod status and resource usage

2. kube-proxy#

Handles networking for Services. It:

  • Sets up NAT rules using iptables or IPVS
  • Routes external and internal traffic to the appropriate Pod IPs

3. Container Runtime#

The engine that runs containers. Kubernetes supports any CRI-compatible runtime like:

  • containerd
  • CRI-O
  • (Previously) Docker (deprecated from v1.24)

🔗 Container runtimes

Add-ons and Enhancements#

Kubernetes Add-ons and Enhancements - Monitoring, Ingress, DNS, and Metrics Tools explored by developer

While not part of the core architecture, most production clusters include these:

  • CoreDNS – Internal DNS resolver
  • Ingress Controller – NGINX, Traefik, or cloud-based ingress for HTTP routing
  • Metrics Server – Provides CPU/memory metrics for autoscaling
  • Prometheus + Grafana – Monitoring and alerting stack
  • Dashboard – Web-based UI for the cluster

Kubernetes Objects (Declarative API)#

The components above run the system, but what you deploy are Kubernetes objects:

ObjectDescription
PodSmallest deployable unit (one or more containers)
ServiceExposes pods as network services
DeploymentManages replica sets for stateless apps
StatefulSetManages stateful workloads with stable IDs
DaemonSetRuns a pod on all (or some) nodes
Job/CronJobHandles batch and scheduled jobs
ConfigMap/SecretInject config or secrets into pods

How It All Works Together#

Let's say you deploy a Deployment with kubectl:

  1. You submit a YAML manifest.
  2. kubectl sends it to the kube-apiserver.
  3. kube-controller-manager notices the new deployment and creates ReplicaSets and Pods.
  4. kube-scheduler picks nodes for those Pods.
  5. kubelet on the nodes talks to the container runtime and starts the containers.
  6. kube-proxy ensures networking is set up so traffic can reach the pod.

All this happens automatically and declaratively — you only specify what you want, not how to do it. Read more about Kubernetes Declarative Model

Final Thoughts#

Kubernetes is powerful because of its modular design and declarative model. Whether you're deploying a blog or scaling microservices to millions of users, the same components orchestrate it all.

Mastering these components gives you deep visibility and control over your infrastructure.
